Mechanical Parameters
|
||||
|
1. Phoroptor swing arm:
Swing angle (up and down)±30°
Rotary arm: rotation angle 0°-300° Up and down moving range: 900mm(lowest point)+600mm Max load:30kg |
||||
|
2. The curvature of instrument:
Swing angle (up and down)±40°
The first rotary arm rotates at an Angle360°； The second rotary arm rotates at an Angle0°- 300° The tray can be 360 ° rotation Up and down moving range:780mm(lowest point)+600mm Max load:30kg |
||||
|
3. Projection arm:
Angle of rotation for rotary arm360°
The tray can be 360 ° rotation Up and down moving range:1030mm(lowest point)+500mm |
||||
|
4. Table size:
350mm x 200mm x 25mm (Can be customized, maximum size is 700mm x 400mm x 40mm)
Max load:50kg |
||||
|
5. Table movement range：
within a semicircle with a radius of 824mm;
vertical movement: 716mm (lowest point) + 300±5mm
|
||||
|
6. Table rotational angle:
The first rotary arm rotates at an Angle0°- 180°； The second rotary arm rotates at an Angle0°- 360° The third rotary arm rotates at an Angle0°- 180°； Table-board rotational angle: 360° |
||||
|
7. Seat parameter:
Lifting range 568mm(lowest position+140+5mm)
Headrest adjusting range 250mm Seat rotation angle 0-3602 Footrest height from ground: minimum 88mm Backrest adjusting angle : 80-180 Max. load:150kg
|
