Sphere
|
-29.00D~+26.75D (0.12D/0.25D/0.50D/1.00D//2.00/3.00D)
|
|
Cylinder
|
0.00D~+8.75D (0.25D/0.5D/1D/2D/3D steps)
|
|
Axis angle
|
0~180° (1°/5°/30°/45°steps)
|
|
Pupillary Distance
|
Distant range:45~75mm (0.5/1.00mm steps)
|
|
Close range: 45~75mm 0.5/1mm steps
|
|
|
Working Distance
|
35-70cm (step: 5cm)
|
|
Rotary Prism
|
0~20 (0.1/0.2/0.5/1/2 steps)
|
|
Cross Cylinder Lens
|
Cross cylinder 0.25D, cross cylinder 0.50D
|
|
Plane Retinoscope
|
+1.50D(67cm) +2.00D(50cm)
|
|
Auxiliary Lens
|
|
|
Pinhole Lens
|
1.0mm
|
|
Maddox
|
Right eye (horizon), left eye (vertical)
|
|
Red and green lens
|
RL(Right eye),GL(Left eye)
|
|
Polaroid
|
Right eye (135°,45°); Left eye (45°,135°)
|
|
Prism
|
Right 6 BU, Left 10BI
|
|
Solid Suprachiasmatic cylinder
|
Cross Cylinder ±0.50D Axis=90°
|
|
Visual degree
|
32°
|
|
Power Supply
|
AC110V-240V (50/60Hz), 90VA
|
|
Net Weight
|
7.1kg
|
